We are your leading repair center for ball screw service industry since 1980 MER specializes in reconditioning all types of ball screw assemblies with internal or external ball return systems.
When your CNC machine tool begins to lose its accuracy, the ball screws and the thrust bearings on the journals are usually the cause. Send your worn or damaged ball screw to us for a complete evaluation. To determine the cost of reconditioning a ball screw, for a no-charge inspection.
In certain cases, a minor wear condition can be corrected properly by reloading the nut and screw with over-sized balls. This reloading procedure is carried out only if the following conditions are met.
If these four critical conditions are met, the ball screw can be reloaded and given up to a 6-month warranty.
Sometimes on integral preloaded nuts (even in good condition), an oversized ball used to offset wear and to establish preload will not run at the proper contact angle. This results in a short wear life and the reload procedure is not carried out. If the screw thread radius and root diameter are not out of tolerance, then they could be polished (or lapped) and proper reconditioning would require a new ball nut only, which is given a 12-month warranty.
When you receive your rebuilt ball screw assembly from MER, it will look and perform as well as or better than a new one. We do the job right, which is why we are able to offer our customers rebuilt ball screws with a 1 year warranty. We have developed a unique and successful repair process that sets us apart from our competition. Specializing allows us to offer our customers the best value and unbeatable turn around time. Choose from our Standard 5 Day Service, our Expedited 2 Day Service, or our Re-Ball Only Service
We repair inch & metric ball screws from any type of machine in almost any diameter. From miniature ball screws less than 2 inches long to very large 30 feet or more, no job is too big or too small for MER. From high precision grinding machines to CNC routers, we rebuild them all
The same day we receive your ball screw, we will perform an initial inspection to determine if it is rebuildable and how much it will cost. There is no charge for our evaluation. At this time we will contact you and give you a guaranteed price for rebuilding your assembly and the actual date that your rebuilt screw will be shipped. No further work will be performed until we get your go ahead.
We Rebuild Ball Screws Made By The Following Ball Screw Manufacturers and Others:
